Maximum Length Of Cat6 Cable Without Data Loss

In addition cat6e cable with grounded foil shielding can reach 10 gigabit ethernet speeds without having to reduce the maximum length of 100 meters.

Maximum length of cat6 cable without data loss. The maximum length you can run cat5 cat5e cat6 and cat6a cable is 100 meters or 328 feet. A short vga cable can manage 1920x1080 without trouble. Category 6 cable cat 6 is a standardized twisted pair cable for ethernet and other network physical layers that is backward compatible with the category 5 5e and category 3 cable standards. The cable standard specifies performance of up to 250 mhz compared to 100 mhz for cat 5 and cat 5e.

With this type of cabling system in place you ll be ready to support next generation wireless 4 pair power over ethernet poe hdbaset and digital buildings and other technologies just entering the picture. The length limit for cat5 also includes any patch cables jacks or couplers that are connected in the run. It should be noted that cat7 cable has harsher distance limits than cat5e cat6 and cat6a. Yet the usb 3 0 standards don t specify a maximum cable length.

Icc introduced the cat6e cable as a premium offering to cat6 just like most bulk cable manufacturers. Icc offers bulk network cable in three performances. When you invest in cat 6a cable you re making a decision to support your organization and its technology infrastructure for the long term. Cat 6 has to meet more stringent specifications for crosstalk and system noise than cat 5 and cat 5e.

For information on audio video cable distance limits click here. Ethernet 100 meters 328 feet there are a few different versions of ethernet cable but they all have a maximum distance of 100 meters 328 feet. Based on a similar principle to hdmi over cat usb 2 0 can also be greatly extended using a cat5 or cat6 cable. If you are using a regular cable max length of 5 meters for 2 0 and max length of 3 meters for 3 0 3 1 with an active cable then the maximum length for usb 2 0 is 25 meters about 82 feet and the maximum recommended length for usb 3 0 3 1 is 15 meters about 49 feet.

Avoid extremely cheap cable as much as possible and stay far far away from anything labeled cca copper clad aluminum as it does not meet the tia eia specifications for cat5e and cat6 cabling. If you require a longer run you will need to put an active component such as a router in between the signals.
